STM32F103C8T6

Name: STM32F103C8T6
Brand: Jinjiana Electronic Co.,Ltd.

Buy STM32F103C8T6

STM32F103C8T6 Overview

ARM® Cortex®-M3 core with embedded Flash and SRAM

The ARM® Cortex®-M3 processor is the latest generation of ARM processors for embedded systems. It has been developed to provide a low-cost platform that meets the needs of MCU implementation, with a reduced pin count and low-power consumption, while delivering outstanding computational performance and an advanced system response to interrupts. The ARM® Cortex®-M3 32-bit RISC processor features exceptional code-efficiency, delivering the high-performance expected from an ARM core in the memory size usually associated with 8- and 16-bit devices.

The STM32F103xx performance line family having an embedded ARM core, is therefore compatible with all ARM tools and software.

Figure 1 shows the general block diagram of the device family.

Technical Data Of STM32F103C8T6

Peripheral		STM32F103Tx		STM32F103Cx		STM32F103Rx		STM32F103Vx
Flash - Kbytes		64	128	64	128	64	128	64	128
SRAM - Kbytes		20		20		20		20
Timers	General-purpose	3		3		3		3
	Advanced-control	1		1		1		1
Communication	SPI	1		2		2		2
	I2C	1		2		2		2
	USART	2		3		3		3
	USB	1		1		1		1
	CAN	1		1		1		1
GPIOs		26		37		51		80
12-bit synchronized ADC Number of channels		2 10 channels		2 10 channels		2 16 channels(1)		2 16 channels
CPU frequency		72 MHz
Operating voltage		2.0 to 3.6 V
Operating temperatures		Ambient temperatures: -40 to +85 °C / -40 to +105 °C (see Table 9) Junction temperature: -40 to + 125 °C (see Table 9)
Packages		VFQFPN36		LQFP48, UFQFPN48		LQFP64, TFBGA64		LQFP100, LFBGA100, UFBGA100
